3.2 Inch 320 x 240 TFT TouchScreen for STM32 Development Board (ER-DPA32320S)
ER-DPA32320S
€27.92
22.70 € tax excl.
3.2 Inch 320 x 240 TFT TouchScreen for STM32 Development Board (ER-DPA32320S)
3.2 Inch 320 x 240 TFT TouchScreen for STM32 Development Board (ER-DPA32320S)
Is this not the cutest little display for the STM32 It features a 3.2" display with 320x240 16-bit color pixels and a resistive touch overlay.
Features
- Work voltage: 2.4V-3.3V
- Backlight type: controlled, active low
- Datal width: 16 bit
- Reset type: active low
- Touch panel type: 4 wire resistive touchscreen
- Resolution:320 x 240
- Driver chip: ILI9320
- Operate temperature: -20℃~70℃
- Storage temperature: -30℃~80℃
Package list
- 3.2 Inch 320 x 240 TFT TouchScreen 1x
ER-DPA32320S
