Me PIR Motion Sensor (MB-11010)

Me PIR Motion Sensor  (MB-11010)

Me PIR sensors are used to detect motion from animals/ humans from about 6m away. If anyone moved in that range, the sensor outputs HIGH on its SIG pin. With a potentiometersoldered on its circuit board, you can adjust its detecting range according to your need. Here are some ideas for application: motion detecting, thief-guarding system, automation switch.

Note: when you give it power supply，you may need to wait 10 seconds until the sensor Initialize.

Features:

•  Adjustable detecting range and high sensity
•  A power indicator LED(Red) and a state indicator(Blue)
•  16mm interval M4 mounting holes, compatible with Makeblock beams
•  2.54mmbreakout pins for connecting with jumper wires
•  Easy wiring with 6 Pin RJ11 interface
•  Arduino library for easy programming

Specification

•  Rated Voltage: 5V
•  working temperture:-20℃～＋70℃
•  Level output voltage: 5V/high, 0V/low
•  Trigger signal: 5V/high
•  Holding time: 2s
•  Detecting angle: 120 degree
•  Detecting distance: max 6m
•  Size:24x48x 32mm(Length x Width x Height)

Documents:

Arduino Library

For more details about this product, please visit Makeblock wiki page. If you have any question about this product or you need technical support, please post it in Makeblock forum
