ESP32-C6 Mini Wi-Fi 6 Dev.Board Type B, 5~36V Bluetooth 5, IEEE 802.15.4, Zigbee 3.0 and Thread (WS-34981)
WS-34981
€6.03
4.90 € tax excl.
ESP32-C6 Mini Wi-Fi 6 Dev.Board Type B, 5~36V Bluetooth 5, IEEE 802.15.4, Zigbee 3.0 and Thread (WS-34981)
ESP32-C6 Mini Wi-Fi 6 Dev.Board Type B, 5~36V Bluetooth 5, IEEE 802.15.4, Zigbee 3.0 and Thread (WS-34981)
ESP32-C6 Mini Wi-Fi 6 Development Board Type B, 5 ~ 36V Wide Voltage Power Supply, Supports Bluetooth 5, IEEE 802.15.4 (Zigbee 3.0 and Thread)
ESP32-C6-Zero-B Mini Wi-Fi 6
Wide Voltage Development Board
Wide Voltage Development Board
Based on ESP32-C6FH8, onboard multi-function GPIO pins
Castellated Module, Suitable For SMD Applications,
Compatible with the ESP32-C6-Zero Pins
Board specifications
- Equipped with a high-performance 32-bit RISC-V processor with clock speed up to 160 MHz, and a low-power 32-bit RISC-V processor with clock speed up to 20MHz
- Built-in 320KB ROM, 512KB HP Static RAM, 16KB LP Static RAM and 8MB Flash memory
- Integrated Wi-Fi 6, Bluetooth 5 and IEEE 802.15.4 (Zigbee 3.0 and Thread) wireless communication, with superior RF performance
- Onboard ceramic antenna (default) and IPEX 4 antenna socket, allowing antenna selection via GPIO7
- Supports 5 ~ 36V wide voltage power supply for industrial applications
- Castellated module, allows soldering directly to carrier boards
- Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios
- Onboard USB Type-C port, adapting 22 × GPIO pins for flexible peripheral function configuration
Version Options
ESP32-C6-Zero-B
without pinheader
ESP32-C6-Zero-B-M
with pre-soldered headers
ESP32-C6 suitable for AIoT applications
Powered by a high-performance 32-bit RISC-V processor and a low-power 32-bit RISC-V processor, the main frequency is up to 160 MHz, Powerful AI Computing Capability & Reliable security features
Wi-Fi 6 and BLE 5 support
Supports Wi-Fi 6, Bluetooth 5 and IEEE 802.15.4 (Zigbee 3.0 and Thread)
Its Bluetooth Low Energy Subsystem Supports Bluetooth 5 (LE) And Bluetooth Mesh
Supports ESP-IDF, Arduino
Comprehensive SDK, Dev Resources, Tutorials To Help You Easily Get Started
What's On Board
- ESP32-C6FH8
Built-in dual processors, up to 160MHz operating frequency - SY8301
Step-down DC/DC converter , supports up to 1A output - USB Type-C port
for downloading program and debugging - WS2812 cool RGB LED
- BOOT button
Press it and then press the RESET button to enter download mode
- RESET button
- 2.4G ceramic antenna
- Antenna selection chip
supports switching between the onboard ceramic antenna (default) and the IPEX 4 antenna socket via GPIO7 - IPEX 4 antenna socket
for connecting external antenna - Adapting ESP32-C6FH8 pins
Pin definition
outline dimensions
Balenie Obsahuje / Package Content
ESP32-C6-Zero-B
ESP32-C6-Zero-B x1
