    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)
    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)
    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)
    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)
    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)
    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)

    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)

    WS-31593
    €20.17

    16.40 € tax excl.

    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)

    Quantity :
    OUT OF STOCK

    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3 (WS-31593)

    Wireless MINIPCIE AX210 NIC, Gigabit Tri-Band Wi-Fi 6E, 802.11AX Standard, Bluetooth 5.3

    Wi-Fi 6 Wireless MiniPCIe AX210 NIC

    Tri-Band



    Bluetooth 5.3



    Wi-Fi 6E

     Wireless-MINIPCIE-AX210 front view Wireless-MINIPCIE-AX210 specifications
    Features at a glance
    • Adopts sixth-generation 802.11AX Wi-Fi standard, provides better performance and compatibility than the previous generation 802.11AC, with lower power consumption and longer service life
    • Supports 2.4G / 5GHz / 6GHz tri-band, the speed up to 574Mbps in the 2.4GHz band and 2400Mbps in the 5GHz / 6GHz band
    • Supports Bluetooth 5.3 standard, longer transmission distance and better stability
    • Adopts MiniPCIe interface
    • Adopts the new generation of MU-MIMO wireless technology, provides better network quality, faster network speed (more than three times), and higher transmission and download efficiency
    • Supports Linux, Windows 10/11, etc.

    Parameters Comparison

    Model
    AX210

    AX200

    RTL8852BE
    Wi-Fi Version Wi-Fi 6E Wi-Fi 6
    Wi-Fi Band 2.4GHz 5GHz 6GHz 2.4GHz 5GHz 2.4GHz 5GHz
    Wi-Fi Rate 574Mbps 2400Mbps 2400Mbps 574Mbps 2400Mbps 574Mbps 1200Mbps
    Interface MiniPCIe Interface
    Bluetooth Version 5.3 5.2
    Technical Support MU-MIMO
    Antenna Connector IPEX-4 Connector
    System Support Linux, Windows 10/11
    Dimensions 29.9 × 26.8 × 3.24 (mm)

    AX210 High Performance Wi-Fi 6E

    Adopts sixth-generation 802.11AX Wi-Fi standard, provides better performance and compatibility than the previous generation 802.11AC, lower power consumption and longer service life

    Wireless-MINIPCIE-AX210 AX210 High Performance Wi-Fi 6E
    Tri-band Wi-Fi

    Supports 2.4GHz / 5GHz / 6GHz tri-band, the speed up to 574Mbps in the 2.4GHz band and 2400Mbps in the 5GHz / 6GHz band

    Wireless-MINIPCIE-AX210 Tri-band Wi-Fi

    Bluetooth 5.3, More Stable Connection

    Signal transmission is stable without lag, can be connected to Bluetooth devices such as mobile phones, computers, gamepads, etc. for wireless connection and transmission

    Wireless-MINIPCIE-AX210 Bluetooth 5.3, More Stable Connection
    Supports MU-MIMO Technology

    Adopts the new generation of MU-MIMO wireless technology, compared with the traditional SU-MIMO mode, it provides better network quality, faster network speed (more than three times), and higher transmission and download efficiency

    Wireless-MINIPCIE-AX210 Support MU-MIMO Technology
    Interface Introduction
    Wireless-MINIPCIE-AX210 Interface Introduction

    Access to antenna via IPEX connector
    Wireless-MINIPCIE-AX210 Access to antenna via IPEX connector

    Outline dimensions
    Wireless-MINIPCIE-AX210 Outline dimensions

    Balenie Obsahuje / Package Content

    1. Wireless-MINIPCIE-AX210 × 1
    2. IPEX 1 to SMA cable × 2
    3. 6DB antenna × 2
    4. Screwdriver × 1
    5. MINIPCIe mounting bracket × 1
    6. Screws pack × 1
    Waveshare Electronics
    WS-31593
