      SIM808 GSM/GPRS/GPS Quad-band 850/900/1800/1900MHz (ER-CT0078SIM) Crowtail

      A new product of crowtail family, it’s a GSM and GPS two-in-one function module which is called Crowtail- SIM808. We add a Crowtail interface to it so that you can use easily. It is very small and based on the latest GSM/GPS module SIM808 from SIMCOM, supports GSM/GPRS Quad-Band network and combines GPS technology for satellite navigation. It has high GPS receive sensitivity with 22 tracking and 66 acquisition receiver channels that will lets you add location-tracking, voice, text, SMS and data to your project in an adorable little package. We can power it with a 3.7V lithium battery, so it can use as a portable module, even you can attach it on your bicycle, it can obtain the speed/location information. In addition, it has a onboard LiPoly battery charging circuitry so that you can take your project on the go. A nice module that can achieve lots of functions. You need it now!

      • Note: On its own, this module can't do anything. It requires a microcontroller to drive it! We suggest and use an Arduino but any 3-5V microcontroller with a UART can send and receive commands over the RX/TX pins.the microUSB connector is for charging only.
      • If you need battery, please click here


        Features

        • Quad-band 850/900/1800/1900MHz
        • GPRS mobile station class B
        • Controlled by AT Command (3GPP TS 27.007, 27.005 and SIMCOM enhanced AT Commands)
        • Integrated GPS/CNSS and supports A-GPS
        • Low power consumption, 1mA in sleep mode
        • Supports GPS NMEA protocol
        • Standard Micro SIM Card
        • GPRS multi-slot class12 connectivity: max. 85.6kbps(down-load/up-load)
        • Indicator LEDs for power and network connectivity
        • uFL connection for external passive GPS & external GSM antenna
        • Any standard 2G SIM slides into a secure connector
        • Standard 4-pole TRRS headphone jack. Use any 'Android' or 'iPhone'-compatible headset with mic

        Specification

        • Sizes: length x Width:50mm x 35mm

        Package list

        • Crowtail- SIM808  1x
        • GSM Antenna 1x
        • GPS Antenna  1x

        Wiki & External links

      ELECROW
      ER-CT0078SIM
